Features General URL transmitters are used for continuous, non-contact level measurement. The radar pulses emittend by the antenna are reflected by the product surface and received back by the antenna. The time gap between the emission and the return of the pulse is named “ flight time”. The flight time is proportional to the product surface distance and the processing by the electronical components inside the RPL allows the level measurement. Through the matrix display it is possible to input all necessary data for the level measurement and to show and recognize false echo signals. The SGMware software is suitable to configure and gauge the HART protocol, by means of PC and COMWAY converter. Continuous, non-contact Radar level transmitters Measurement range up to 70m Measurement accuracy: ±10mm Electrical supply 24Vdc or 230Vac al servizio dell'applicazione • Continuous, non-contact level measurement for solids, liquids, pulps and slurries • Measurement not affected by product physical variation, temperature changes, powders or vapours. • Two measure ranges: up to 40m and to 70m • Process temperature up to 180°C • Process pressure up to 40bar • Easy on-site configuration via menu-driven matrix display (plug-in) • Easy on-site calibration without product handling. Empty and full distance setting via matrix display • 2-wire technology • Analogue output 4÷20mA • HART protocol (optional) • Level measurement and echo signal curve visualisation on matrix display • Storage and recognation system for false echo signals
General URL transmitters are used for continuous, non-contact level measurement. The radar pulses emittend by the antenna are reflected by the product surface and received back by the antenna. The time gap between the emission and the return of the pulse is named “ flight time”. The flight time is proportional to the product surface distance and the processing by the electronical components inside the RPL allows the level measurement. Through the matrix display it is possible to input all necessary data for the level measurement and to show and recognize false echo signals. The SGMware software is suitable to configure and gauge the HART protocol, by means of PC and COMWAY converter.
